Lifecycle
- Obsolete Date 30-06-2026
Specifications
- Expansion slots 4, for detailed descriptions refer to the QuickSpecs
- Storage controller HPE MR216i-p Gen11 x16 Lanes without Cache PCI SPDM Plug-in Storage Controller
- Optical drive type None ship standard. Optional: SATA 9.5mm DVD-RW/DVD-ROM Optical Drive
- Weight 27.558 lb
- Product dimensions (metric) 49.87 x 59.87 x 33.61 cm
- Product dimensions (imperial) 19.63 x 23.57 x 13.23 in
- Weight 12.5 kg
- Power supply type 2x HPE 800W Flex Slot Titanium Hot Plug Low Halogen Power Supply Kit
- Processor name Intel® Xeon® E-2436 (6 core, 2.90 GHz, 18 MB Intel® Smart Cache, 65W)
- Included memory 32 GB (1×32 GB UDIMM, 4800 MT/s)
- Included drives 2x HPE 480GB SATA 6G Read Intensive SFF BC Multi Vendor SSD
- System fan features 1x Non-hot plug non-redundant system fan
- Infrastructure management HPE iLO Standard with intelligent provisioning (embedded), HPE OneView Standard (requires download) (standard) HPE iLO Advanced, HPE OneView Advanced (optional, requires licenses), and HPE Compute Ops Management (optional subscription available).
- Memory type HPE DDR5 Standard Memory
- Processor cache 18 MB Intel® Smart Cache
- Processor core available 6 core
- Processor number 1 processor included
- Processor speed 2.90 GHz
- Network controller Embedded 1Gb 4-Port Ethernet Adapter
- Form factor 4U Tower
- Warranty Server warranty includes 3-year parts, 1-year labor, and 1-year on-site support with next business day response. Additional information regarding worldwide limited warranty and technical support is available at: https://support.hpe.com/hpesc/public/docDisplay?docId=sd00004309en_us. Additional HPE support and service coverage for your product can be purchased locally. For information on availability of service upgrades and the cost for these service upgrades, visit www.hpe.com/services/support.
- Security Embedded Trusted Platform Module (TPM) 2.0 enabled by default. For servers shipping to China, the TPM is disabled. For full security features refer to the QuickSpecs.
Quickspecs
Overview
Do you need a reliable enterprise-class tower server that can easily meet your budget? The HPE ProLiant ML30 Gen11 Plus server is a powerful yet affordable tower server designed for small offices, remote and branch offices to run on-premises and hybrid cloud solutions, delivering enterprise-class performance, security, reliability, and expandability at a low cost. Hewlett Packard Enterprise builds security right into the server with HPE iLO silicon root of trust. A redundant power supply option and up to four LFF or eight SFF hot-plug HDDs provide availability and flexibility. The enhanced expansion capability, now including PCIe Gen5, allows you to upgrade with serial attached SCSI (SAS) controllers or networking cards as your business grows, which can give you an extra edge. Power your business now with an HPE ProLiant ML30 Gen11 server.
What’s new
- 4800 MT/s HPE DDR5 Standard Memory UDIMM offering: 16 GB and 32 GB, maximum 128 GB memory capacity.
- Four expansion slots for more flexible usage, including one PCIe Gen5 x16.
- Onboard M.2 NVMe SSD support.
- Dedicated HPE iLO port and serial port kit option.
- Supports Intel® Xeon® E Processors up to 8 cores 95W.
Features
Intelligent Management Automation
The HPE ProLiant ML30 Gen11 server simplifies and automates management tasks, establishing a solid foundation for a hybrid cloud platform enabled by automation.
Embedded in Hewlett Packard Enterprise servers, HPE Integrated Lights-Out (iLO) is an exclusive core intelligence that monitors server status, providing the means for reporting, ongoing management, service alerting, and local or remote management to quickly identify and resolve issues.
Automation and software-defined control reduce time spent on provisioning and maintenance, as well as reduce deployment times.
The HPE Trusted Platform Module (TPM) works to increase data security by storing the encryption startup key in hardware on the server, providing a more secure environment
Powerful Yet Affordable Server for Your Daily Office Workloads
The HPE ProLiant ML30 Gen11 server is powered by up to 8 cores Intel® Xeon® E Processors and up to 128 GB 4400 MT/s DDR5 ECC UDIMM, delivering abundant performance for small- to mid-sized business applications.
With up to 80 TB storage capacity, the HPE ProLiant ML30 Gen11 is an ideal data storage platform allowing your business to accommodate an increasing amount of data as you grow. An onboard M.2 slot with NVMe SSD support delivers outstanding speed for a boot drive. [1]
An optional dedicated HPE iLO port allows you to dedicate more bandwidth to network functions and achieve higher network speeds.
The embedded Intel VROC SATA Hybrid RAID ships standard, and the HPE Smart Array essentials and performance controllers allow you the flexibility to choose the 12Gbps controller best suited to your environment.
Four expansion slots for more flexible usage, including one PCIe Gen5 x16 for increased bandwidth. [2]
The HPE ProLiant ML30 Gen11 server offers flexibility in different storage needs. With a choice of 4 Large Form Factor (LFF) non-hot-plug, hot-plug, or 8 Small Form Factor (SFF) hot-plug drive options, you can find a right fit for your growing business.
The selective HPE 500W, 800W and 1000W Flex Slot redundant power supplies enhance the reliability, and lets you share spares across multiple server platforms.
The HPE ProLiant ML30 Gen11 server offers a complete set of embedded HPE Integrated Lights Out (iLO 6) management features.
A Variety of Enterprise-Class Features to Achieve Business Growth with Low TCO
Security Innovations
The HPE ProLiant ML30 Gen11 protects your business with innovations in firmware protection, malware detection, and firmware recovery — right down to the silicon.
Millions of lines of firmware code run before the server operating system boots. Runtime firmware validation, enabled by HPE iLO Advanced Premium Security Edition, checks the server firmware every 24 hours verifying the validity and credibility of essential system firmware.
Secure recovery allows server firmware to roll back to the last known-good state or to factory settings after the detection of compromised code.
Compatible products
- HPE 2.4TB SAS 12G Mission Critical 10K SFF BC 3-year Warranty 512e Multi Vendor HDD
- HPE 300GB SAS 12G Mission Critical 10K SFF BC 3-year Warranty Multi Vendor HDD
- HPE 3 Year Tech Care Essential DL20/ML30 Smart Choice Service
- Red Hat Resilient Storage 2 Sockets or 2 Guests 1 Year Subscription E-LTU
- HPE 500W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit
- HPE 3.2TB SAS 24G Mixed Use SFF BC Multi Vendor SSD
- MS WS25 16C Std ROK EU SW
- HPE MR416I-P GEN11 SPDM STORAGE CNTLR
- Red Hat Enterprise Linux for SAP for Virtual Datacenters 5yr Subscription 24×7 Support E-LTU
- Microsoft Windows Server 2025 50 Users CAL WW LTU
- MS WS25 16C Std Add Lic WW SW
- HPE 16GB (1x16GB) Single Rank x8 DDR5-4800 CAS-40-39-39 Unbuffered Standard Memory Kit
- RHEL Svr 2 Sckt 4 Gst 5yr 24×7 E-LTU
- HPE StoreEver LTO-8 Ultrium 30750 Internal Tape Drive
- Broadcom BCM57504 Ethernet 10/25Gb 4-port SFP28 Adapter for HPE
- HPE 5YTCBas DL20/ML30 Smart Choice SVC
- HPE 7.68TB SATA RI SFF BC MV SSD
- HPE 480GB SATA 6G Read Intensive SFF BC Multi Vendor SSD
- RH HA 2 Sckt/2 Gst 5yr E-LTU
- Red Hat Enterprise Linux for SAP for Virtual Datacenters 3yr Subscription 24×7 Support E-LTU
- HPE 5 Year Tech Care Essential DL20/ML30 Smart Choice Service
- RHEL Svr 2 Sckt 4 Gst 3yr 9×5 E-LTU
- Red Hat Enterprise Linux Server 2 Sockets or 2 Guests 3 Year Subscription 9×5 Support E-LTU
- MS WS25 5Usr CAL WW LTU
- HPE 480GB SATA 6G Mixed Use SFF BC Multi Vendor SSD
- HPE ML30 Gen9 Tape Drive Cable Kit
- RHEL Svr 2 Sckt 4 Gst 5yr 9×5 E-LTU
- Red Hat Enterprise Linux for SAP (Physical/Virtual Nodes) 5yr Subscription 24×7 Support E-LTU
- Red Hat Enterprise Linux Server 2 Sockets 1 Guest 1 Year Subscription 9×5 Support E-LTU
- BCM 57414 10/25GbE 2p SFP28 Adptr
- RHEL Svr 2 Sckt 4 Gst 1yr 9×5 E-LTU
- RH RS 2 Sckt Unltd Gst 3yr E-LTU
- MS WS25 RDS 5USR CAL WW LTU
- Red Hat Enterprise Linux for SAP (Physical/Virtual Nodes) 5yr Subscription 9×5 Support E-LTU
- Microsoft Windows Server 2025 2-core Standard Additional License WW SW
- Red Hat Enterprise Linux Server 2 Sockets or 2 Guests 1 Year Subscription 9×5 Support E-LTU
- HPE 1 Mini SAS HD – 4 Mini SAS FO 4
- HPE 3.84TB SATA 6G Read Intensive SFF BC Multi Vendor SSD
- MS WS25 4C Std Add Lic WW SW
- Red Hat Enterprise Linux for Virtual Datacenters 2 Sockets 5 Year Subscription 24×7 Support E-LTU
- HPE 1.92TB SATA 6G Mixed Use SFF BC Multi Vendor SSD
- Broadcom BCM5719 Ethernet 1Gb 4-port BASE-T Adapter for HPE
- Red Hat Enterprise Linux for SAP (Physical/Virtual Nodes) 3yr Subscription 24×7 Support E-LTU
- HPE 1.92TB SATA 6G Read Intensive SFF BC Multi Vendor SSD
- Microsoft Windows Server 2025 1 Device CAL WW LTU
- Red Hat High Availability 2 Sockets or 2 Guests 1 Year Subscription E-LTU
- HPE BladeSystem c-Class 10Gb SFP+ SR Transceiver
- HPE 960GB SATA 6G Mixed Use SFF BC Multi Vendor SSD
- HPE 600GB SAS 10K SFF BC MV HDD
- MS WS25 RDS 1Usr CAL WW LTU
- HPE iLO Advanced Electronic License with 3yr Support on iLO Licensed Features
- Red Hat High Availability 2 Sockets or 2 Guests 3 Year Subscription E-LTU
- RHEL Svr 2 Sckt 4 Gst 1yr 24×7 E-LTU
- HPE 1.8TB SAS 10K SFF BC 512E MV HDD
- MS WS25 1USR CAL WW LTU
- HPE 32GB 2RX8 PC5-4800B-E STND KIT
- HPE Proliant DL/ML Startup Service
- RHEL Svr 2 Sckt 1 Gst 1yr 24×7 E-LTU
- HPE Proliant DL/ML Install Service
- HPE 9.5mm SATA DVD-RW Optical Drive
- HPE 1000W Flex Slot Titanium Hot Plug Power Supply Kit
- HPE Smart Array E208e-p SR Gen10 (8 External Lanes/No Cache) 12G SAS PCIe Plug-in Controller
- HPE ProLiant ML30 Gen11 iLO/NIC/M.2/COM Port Kit
- MLX MCX631102 10/25GBE 2P SFP28 ADPTR
- Red Hat Enterprise Linux for Virtual Datacenters 2 Sockets 5 Year Subscription 9×5 Support E-LTU
- HPE Smart Array Secure Encryption E-LTU
- HPE 800W Flex Slot Titanium Hot Plug Low Halogen Power Supply Kit
- Red Hat Enterprise Linux for Virtual Datacenters 2 Sockets 3 Year Subscription 24×7 Support E-LTU
- SUSE Linux Enterprise High Availability Extension 1-2 Sockets 3 Year Subscription E-LTU
- Red Hat Resilient Storage 2 Sockets or 2 Guests 3 Year Subscription E-LTU
- RHEL Svr 2 Sckt 4 Gst 3yr 24×7 E-LTU
- HPE 960GB SATA 6G Read Intensive SFF BC Multi Vendor SSD
- Red Hat Enterprise Linux Server 2 Sockets or 2 Guests 1 Year Subscription 24×7 Support E-LTU
- RH HA 2 Sckt Unltd Gst 1yr E-LTU
- Red Hat Enterprise Linux Server 2 Sockets or Guests 5 Year Subscription 9×5 Support E-LTU
- HPE 96W Smart Storage Lithium-ion Battery with 260mm Cable Kit
- HPE 960GB SAS 12G Mixed Use SFF BC Value SAS Multi Vendor SSD
- HPE LTO-7 Ultrium 15000 Internal Tape Drive
- RH RS 2 Sckt Unltd Gst 1yr E-LTU
- HPE C13 – KSC- 8305 KR 250V 10Amp 1.83m Power Cord
- Red Hat Enterprise Linux for SAP for Virtual Datacenters 5yr Subscription 9×5 Support E-LTU
- HPE iLO Advanced 1-server License with 3yr Support on iLO Licensed Features
- HPE ML150 Gen9 Smart Storage Battery Holder Kit
- Red Hat Enterprise Linux Server 2 Sockets or 2 Guests 3 Year Subscription 24×7 Support E-LTU
- HPE MR216i-p Gen11 x16 Lanes without Cache PCI SPDM Plug-in Storage Controller
- Red Hat Enterprise Linux for Virtual Datacenters 2 Sockets 1 Year Subscription 9×5 Support E-LTU
- RH HA 2 Sckt Unltd Gst 3yr E-LTU
- Microsoft Windows Server 2025 4-core Datacenter Additional License WW SW
- HPE 3YTCBAS DL20/ML30 SMART CHOICE SVC
- Red Hat Resilient Storage 2 Sockets Unlimited Guests 5yr Subscription E-LTU
- HPE Mobile USB DVD-RW Optical Drive
- RH HA 2 Sckt Unltd Gst 5yr E-LTU
- HPE iLO Advanced 1-server License with 1yr Support on iLO Licensed Features
- Red Hat Enterprise Linux for SAP (Physical/Virtual Nodes) 3yr Subscription 9×5 Support E-LTU
- Broadcom BCM57416 Ethernet 10Gb 2-port BASE-T Adapter for HPE
- HPE C13 – CEE-VII EU 250V 10Amp 1.83m Power Cord
- Broadcom BCM57412 Ethernet 10Gb 2-port SFP+ Adapter for HPE
- HPE ML Gen10 Tower to Rack Conversion Kit with Sliding Rail Rack Shelf and Cable Management Arm
- Microsoft Windows Server 2025 10 Users CAL WW LTU
- HPE 1 Mini SAS HD – 4 Mini SAS FO 2M Cbl
- Red Hat Enterprise Linux for SAP for Virtual Datacenters 3yr Subscription 9×5 Support E-LTU
- HPE 240GB SATA 6G Read Intensive SFF BC Multi Vendor SSD
- Red Hat Enterprise Linux for Virtual Datacenters 2 Sockets 1 Year Subscription 24×7 Support E-LTU
- HPE 3.84TB SAS RI SFF BC VS MV SSD
- HPE 1.83m 10A C13-UL Dom Pwr Cord
- RH RS 2 Sckt/2 Gst 5yr E-LTU
- HPE iLO Advanced Electronic License with 1yr Support on iLO Licensed Features
- HPE Smart Storage Hybrid Capacitor with 260mm Cable Kit
- HPE 7.68TB SAS 12G Read Intensive SFF BC Value SAS Multi Vendor SSD
- Red Hat Enterprise Linux for Virtual Datacenters 2 Sockets 3 Year Subscription 9×5 Support E-LTU
- HPE 1.2TB SAS 12G Mission Critical 10K SFF BC 3-year Warranty Multi Vendor HDD
- HPE NS204i-u Gen11 NVMe Hot Plug Boot Optimized Storage Device
- HPE 9.5mm SATA DVD-ROM Jb Gen9 Kit
Documents
- HPE ProLiant ML30 Gen11 server beats competition on all four base metrics of SPEC CPU® 2017 benchmark
- Enterprise server acceleration from edge to data center
- HPE ProLiant ML30 Gen11 QuickSpecs
[1] HPE ProLiant ML30 Gen11 server supports one onboard M.2 SSD with PCIe 5.0 x2 bandwidth or SATA.
[2] Compared with PCIe Gen4 x16.
