Switch-uri
Switch D-Link DGS-1210-52MP, 48 port, 10/100/1000 Mbps
Producator:
D-link
Disponibilitate:
Stoc epuizat
9.423,00 lei
Stoc epuizat
Numar porturi
48x RJ-45
Porturi
48x RJ45
4x SFP
4x SFP
Viteza de transfer
10/100/1000 Mbps
Management
Da
Putere consumata
483.1 W
Alimentare
100 – 240 V
PoE
Da
PoE Budget
370 W
Dimensiuni
440 x 430 x 44 mm
Greutate
5.78 Kg
Montare in rack
19 inch
Memorie Buffer
3 MB
Adrese MAC
16K
Metoda forwarding
77.4 Mpps
Routing/Switch Fabric
104 Gbps
Standarde
802.3af, 802.3at
Altele
4x SFP ports
| LAN-Port-Type | Gigabit |
|---|---|
| Layer | Layer-2 |
| Stackable | Yes |
| Rackable | Yes |
| Redundant-PSU | No |
| Jumbo frames support | Yes |
| Link aggregation | Yes |
| Power supply included | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Storage relative humidity (H-H) | 0 – 95% |
| Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x |
| Full duplex | Yes |
| Rack mounting | Yes |
| VLAN support | Yes |
| Quality of Service (QoS) support | Yes |
| Static route | Yes |
| Web-based management | Yes |
| System event log | Yes |
| Switch type | Managed |
| Port mirroring | Yes |
| Form factor | 1U |
| MAC address filtering | Yes |
| Access Control List (ACL) | Yes |
| Internal memory | 256 MB |
| Power over Ethernet (PoE) | No |
| Auto MDI/MDI-X | Yes |
| Flow control support | Yes |
| IGMP snooping | Yes |
| Number of power supply units | 1 |
| Copper ethernet cabling technology | 10BASE-T, 100BASE-TX, 1000BASE-T |
| Auto-negotiation | Yes |
| Installed SFP modules quantity | 0 |
| Configuring Location Settings (CLI) | Yes |
| 10G support | No |
| Half duplex | Yes |
| Broadcast storm control | Yes |
| Spanning tree protocol | Yes |
| Multicast support | Yes |
| MAC address table | 16000 entries |
| Loop protection | Yes |
| Flash memory | 32 MB |
| Basic switching RJ-45 Ethernet ports quantity | 48 |
| Switching capacity | 104 Gbit/s |
| Memory type | DDR3-SDRAM |
| Total Power over Ethernet (PoE) budget | 370 W |
| ARP inspection | Yes |
| MIB support | Y |
| Store-and-forward | Yes |
| Power connector | AC-in jack |
| Combo SFP ports quantity | 4 |
| Packet buffer memory | 12 MB |
| Head-of-line (HOL) blocking | Yes |
| Number of VLANs | 256 |
| Jumbo frames | 10000 |
| Forwarding rate | 77.4 Mpps |
| DHCP features | DHCP server, DHCP client |
| Mean time between failures (MTBF) | 236667 h |
| Heat dissipation | 1634.01 BTU/h |
| Power over Ethernet (PoE) ports quantity | 48 |
| Number of static routes | 256 |
| Porturi RJ 45 | 28+ |
| Viteza Transfer | Gigabit |
| Porturi SFP | 1-2 |
| Montare in Rack | Da |
| Management | Da |
| PoE | Da |
| LAN ports | ≥49 |
| Product colour | Black |
| Storage temperature (T-T) | -40 – 70 °C |
| Operating relative humidity (H-H) | 0 – 95% |
| Sustainability compliance | Yes |
| LED indicators | Yes |
| Depth | 430 mm |
| Power source | AC |
| AC input voltage | 100 – 240 V |
| AC input frequency | 50/60 Hz |
| Width | 440 mm |
| Height | 44 mm |
| Compliance certificates | BSMI, CB, CCC, cUL |
| Noise level | 52.4 dB |
| Weight | 6.26 kg |
| Power consumption (max) | 478.9 W |
| Producator | D-LINK |
| Garantie | 60 |
