-12%

Placa de Baza GIGABYTE B850M AORUS ELITE WIFI6E AM5, 4x

SKU: B850M A ELT WF6E
Producator: Gigabyte
Disponibilitate:

8 în stoc


1.520,99 lei 1.736,00 lei

8 în stoc

Placa de Baza GIGABYTE B850M AORUS ELITE WIFI6E AM5, 4x DDR5, 1x DP 1x HDMI, 2x PCIE x16, 2x M.2, 4x SATA 6GB/s, mATX

SKU: B850M A ELT WF6E Categorie:
PCI

0

Serial-or-Paralel

No/No

Video-Connection

HDMI/DP

Wi-Fi

Yes

USB3

4-8

Onboard-CPU

No

Product colour

Black

RAID support

Yes

Component for

PC

DisplayPort version

1.4

Memory channels

Dual-channel

Top Wi-Fi standard

Wi-Fi 6E (802.11ax)

Ethernet LAN

Yes

HDMI ports quantity

1

Ethernet LAN (RJ-45) ports

1

Bluetooth version

5.3

HDMI version

1.4

Headphone outputs

1

Processor manufacturer

AMD

Weight

1.78 kg

Depth

244 mm

WLAN controller model

Realtek RTL8852CE

USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity

2

Products per shipping (inner) case

1 pc(s)

Batteries included

Yes

USB 2.0 ports quantity

4

PCI Express x16 (Gen 3.x) slots

1

Audio output channels

7.1 channels

Line-in

Yes

PCI Express x16 (Gen 5.x) slots

1

Supported storage drive types

HDD & SSD

Number of M.2 (M) slots

2

Cooling type

Passive

Maximum resolution

3840 x 2160 pixels

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity

5

S/PDIF out port

Yes

Screws included

Yes

Digital audio optical out

1

Package depth

268 mm

DisplayPorts quantity

1

VGA (D-Sub) ports quantity

0

Parallel processing technology support

Not supported

DVI-D ports quantity

0

DirectX version

12.0

Windows operating systems supported

Windows 10 x64, Windows 11 x64

Package height

68 mm

Model Chipset

B850

Gaming

Da

Format

Micro-ATX (mATX)

Soclu Procesor

Socket AM5

Tip Memorie:

DDR5

Numar sloturi memorie

4

Memorie maxima

256 GB

Tip slot interfata grafica

N/A

Chipset audio integrat

Realtek

Canale audio

7.1

Wireless

Da

BLUETOOTH

Da

HDMI

Da

Thunderbolt

Nu

Sloturi M.2

2

RJ-45 LAN

1

Number of memory slots

4

Memory slots type

DIMM

Unbuffered memory

Yes

USB 2.0 connectors

2

USB 3.2 Gen 1 (3.1 Gen 1) connectors

1

USB 3.2 Gen 2 (3.1 Gen 2) connectors

0

Number of SATA III connectors

4

Front panel audio connector

Yes

ATX Power connector (24-pin)

Yes

CPU fan connector

Yes

EPS power connector (8-pin)

Yes

Motherboard form factor

micro ATX

Motherboard chipset family

AMD

BIOS type

UEFI AMI

BIOS memory size

256 Mbit

Clear CMOS jumper

Yes

Width

244 mm

Supported memory types

DDR5-SDRAM

Maximum internal memory

256 GB

Maximum internal memory per slot

64 GB

Number of HDDs supported

4

Front panel connector

Yes

Number of CPU fan connectors

2

Number of chassis fan connectors

4

TPM connector

Yes

Number of water pump connectors

2

RGB LED pin header

Yes

Number of RGB LED pin headers

4

WiFi-AP antenna jack

2

Ethernet interface type

2.5 Gigabit Ethernet

LAN controller

Realtek RTL8125

PC health monitoring

Fan, Temperature, Voltage, Water cooling

Power source type

ATX

1st M.2 largest key size

25110

1st M.2 highest PCI Express generation

5.0

2nd M.2 largest key size

22110

2nd M.2 highest PCI Express generation

4.0

ACPI version

5.0

Desktop Management Interface (DMI) version

2.7

System Management BIOS (SMBIOS) version

2.7

Battery weight

3 g

Lithium weight per battery

0.07 g

Number of battery cells

1

Battery technology

Lithium-Manganese Dioxide (LiMnO2)

Battery type

CR2032

Height

35 mm

Antenna included

Yes

Bundled software

Norton® Internet Security (OEM version) LAN bandwidth management software

USB 3.2 Gen 2x2 connectors

1

12V power connector

Yes

ECC сompatibility

Non-ECC

Number of storage drives supported

6

Package width

270 mm

RAID levels

0, 1, 10

Processor socket

Socket AM5

Supported processor sockets

Socket AM5

Compatible processor series

AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series

Motherboard chipset

AMD B850

Number of EPS power connectors (8-pin)

1

Package weight

1.97 kg

Supported storage drive interfaces

M.2, PCI Express 4.0, PCI Express 5.0, SATA III

Audio Chip

Realtek ALC1220-VB

MB-Format

ATX

PCI-Ex1

0

RAM-Slots

4

USB Type-C

N/A

MB-Socket

AM5

PCI-Ex16

2

Supported memory clock speeds

8200,8000,7950,7900,7800,7600,7400,7200,7000,6800,6600,6400,6200,6000,5800,5600,5200,4800,4400 MHz
